Dimensions
Wing span: 4.9 m 16 ft
Length: 3.9 m 12.8 ft
Weight
Empty weight: 80 – 90 kg 176 – 200 lbs
Gross weight : 170 – 190 kg 375 – 419lbs
Designer says 70 – 75 Kg but very few builders achieve this.
Performance
Take off roll: 200 m 600 ft
Cruise speed: 100-115 mph 85-100 kts
Max permitted speed (VNE) 160 mph 139 kts
Stall speed: (w,w/o flap) 45 -56mph 39 -49 kts
Rate of climb: 5 m / sec 800-1200ft/min
Ceiling: 4500 m 14,800 ft
Fuel capacity: 23 litres 6 gallons(US)
Fuel consumption: 9 l/h (corresponds to 4.8 l/100 km)
Range: 400 km 280 miles
Flight Data:
Vmax 140 kts
Va 100 kts
Max with flaps 70 kts with flap 12 and 27 degree
Vs 49 clean 44 T/O config 39 full flaps
Max cross wind 12 kts
C of G 24 – 40 % of chord (150mm – 250mm from leading edge)
Cost of plans approx $750 US
Cost of building $ 20,000 – $45,000 US
Time to build 2000++ hrs 5 – 15 yrs of spare time
